Solid Fuel Residential Boilers

Solid fuel floor heating is a type of underfloor heating system used to heat a building or a space, typically using solid fuels such as wood, coal, or sawdust as fuel. In this system, the heat obtained from the combustion of solid fuels is transmitted to the floor through special pipes or panels and spreads homogeneously upwards from the floor. Thus, by heating the floor of the space, comfortable heating is provided in the room.

WhatsApp Quick Contact WhatsApp Quick Contact
Solid Fuel Residential Boilers
Certificates
Locomotive Series
Locomotive Series - Manually Loaded Solid Fuel Hot Water Boiler
  • Heat Capacity : 25,000 Kcal/h - 1,500,000 Kcal/h
  • Operating Temperature : 60°C - 85°C
  • Design Type : Horizontal – Floor Type – 3 Pass – Semi-cylindrical
  • Fuel Types : Lignite Coal, Olive Pomace, Olive Pit, Wood, Wood Chips, Sawdust, Plywood Waste, Particleboard Pieces, Nut Shells
  • Combustion System : Manual fuel feeding, cast iron grate in the combustion chamber
View
Manually Loaded Solid Fuel Hot Water Boiler
Obus Series
Obus Series - Solid Fuel Hot Water Boiler
  • Heat Capacity : 25,000 kcal/h - 60,000 kcal/h
  • Operating Temperature : 60°C - 85°C
  • Design Type : Vertical - Floor type - 4 Pass - Prismatic
  • Fuel Types : Lignite Coal, Olive Pomace, Olive Pit, Wood, Wood Chips, Plywood Waste, Particleboard Pieces, Nut Shells, Almond Shells
  • Combustion System : Bottom-fed, Side Mechanical Auger, and Manual wood loading compartment
View
Solid Fuel Hot Water Boiler
Individual Ekopel Series
Individual Ekopel Series - Solid Fuel Hot Water Boiler
  • Heat Capacity : 25,000 kcal/h - 60,000 kcal/h
  • Operating Temperature : 60°C - 85°C
  • Design Type : Vertical - Floor-mounted - 3-pass - Prismatic
  • Fuel Type : Lignite Coal, Pellet, Olive Pit, Wood, Wood Chips, Sawdust, Wood Shavings, Plywood Waste, Suta Pieces, Nut Shell, Cherry Pit, Walnut Shell, Sunflower, Compressed Bio Pellets, Acorn, Peanut Shell, Almond Shell
  • Combustion System : Bottom-fed, Rear Mechanical Auger
View
Solid Fuel Hot Water Boiler

Working Principle of Solid Fuel Floor Heating

  1. Fuel Feeding: In this type of system, solid fuels used (such as wood, coal, sawdust) are fed into a special combustion chamber or unit. Here, the combustion of the fuel is ensured and heat is produced during combustion.

  2. Heat Transfer: The high-temperature gases resulting from the combustion process are transmitted to special pipes or panels that carry the heat. These pipes or panels are laid under the floor.

  3. Floor Heat Absorption: Heat carrying pipes or panels absorb the heat in the floor and transmit this heat to the surface of the floor, heating the floor.

  4. Room Temperature: The heated floor evenly distributes heat into the room, ensuring the space is heated. At the same time, the heat concentrated in areas close to the surface of the floor keeps the soles of the feet warm.
