Individual Ekopel Series - Solid Fuel Hot Water Boiler
Individual Ekopel Series solid fuel hot water boiler is designed to fit into the smallest spaces and evenly distributes heat across all surfaces thanks to its 3-pass design, ensuring maximum heat transfer and fuel savings
Technical Specifications
-
Heat Capacity25,000 kcal/h - 60,000 kcal/h
-
Operating Temperature60°C - 85°C
-
Design TypeVertical - Floor-mounted - 3-pass - Prismatic
-
Fuel TypeLignite Coal, Pellet, Olive Pit, Wood, Wood Chips, Sawdust, Wood Shavings, Plywood Waste, Suta Pieces, Nut Shell, Cherry Pit, Walnut Shell, Sunflower, Compressed Bio Pellets, Acorn, Peanut Shell, Almond Shell
-
Combustion SystemBottom-fed, Rear Mechanical Auger
-
Control PanelDigital Temperature Thermostat Controlled
-
Flue OutletRear Top
-
Hot Water Inlet/OutletFlanged
-
HS Code840310900000
Coal and pellet boiler, with capacities ranging from 25,000 to 60,000 kcal/h, offers ease of use for individual heating. The Digital Control Panel maintains a constant water temperature, maximizing fuel savings.
All materials used in production are certified. Our boilers, produced according to TS EN 497 standards, are certified with the 97/23/EC Pressure Equipment Directive Module H Full Quality Assurance. Our products are manufactured using S235 JR quality steel. The boiler tubes used in our products are made from P235GH and higher quality steel, in accordance with TS EN 10217-2 standards.
Our boilers are designed for fuel with a minimum calorific value of 4,500 kcal/h (flame temperature 1200°C). For burning lower-calorific fuels, please contact our company.
Our insulation minimizes heat losses and provides fuel savings in our boilers. If desired, antifreeze can be used in the system to prevent the risk of freezing in the installation.
