Fast Series - Liquid and Gas-Fired Hot Air Boiler

Fast Series liquid and gas-fired hot air boiler is manufactured with a combustion chamber and first-pass tubes made from stainless steel.

The other parts of the Fast Series hot air boiler are made from S 235 JR black steel. The insulation is done with 100mm rock wool, ensuring minimal heat loss. Our products are manufactured using boiler tubes made from P235GH and higher quality steel in accordance with TS EN 10217-2 standards.

WhatsApp Quick Contact

Technical Specifications

Heat Capacity

125,000 Kcal/h – 2,500,000 Kcal/h - 116 kW - 2906 kW
Operating Temperature

60 °C - 150 °C
Design Type

Vertical 4-pass, TS EN 10217-2 standard P235 GH, Combustion chamber and first pass made of stainless steel
Fuel Types

LNG, Propane, CNG, Natural Gas, LPG, Biogas, Diesel, Fuel Oil, or Dual-Fuel
Combustion System

Universal burner
Control Panel

Digital Temperature Controlled
Flue Exit

Rear, with flue gas temperature safety sensor
Hot Air Outlet

Top Straight Duct
Optional Features

PLC touch control - HMI screen, Modbus, TCP/IP, and other communication protocols
HS Code

732290000000

Our Fast Series liquid and gas-fired hot air boilers have the flexibility to work in harmony with different combustion systems. Thanks to the Turbo Fan system, secondary combustion is achieved, offering 20-40% fuel savings.

With its 3-pass design, the heat is evenly distributed across all surfaces, ensuring maximum heat transfer and fuel savings. Our boilers operate quietly, preventing noise pollution. More heat is provided with less fuel.

By maintaining the desired air temperature with the thermostat control, fuel savings are maximized. The boiler features a combustion chamber resistant to high temperatures and cast iron components.
